The General's features
built in LEVELIZA
The General is currently the Worlds' only active speaker that has an inbuilt Leveliza and can engineer its own levels accordingly.
Full Range mode
Although predominantly designed as a mid/high speaker, in this mode the Generals will respond down to about 50hz, which gives them the ability to be really useful as a full range solution in applications not requiring a strong sub response.
Mid/High mode
In this mode the Generals can perform at their loudest and respond down to about 150hz with a fairly gentle 12db/octave rolloff.
"Limitiza" Circuit
The unique "Limitiza" circuit in the Generals continuously monitors the activity of the limiters. It ignores slight or "soft" limiting, but if it detects any of the limiters are consistently limiting significantly or "hard" then it gently eases back the overall system gain until the limiting action is only soft. When an active speaker is slightly or "soft" limiting it means it is running as loud as it can without significantly compromising it's sound in any way.
The Limitiza means that you can
try to "overdrive" the Generals as much as you like, but they will just maintain this ultimate 100% output level without compromise in sound quality or losing dynamic range.
| Dimensions & Weight: | 360w x 600h x 450d x 45kg approx |
| Mounting hardware: | 35mm pole socket on base |
| Frequency response: | approx 50hz-20khz in full range mode or 150-20khz in mid/high mode |
| Amplifiers: | Bi-amped - Class AB - 1.2KW RMS low frequency and 0.3KW RMS high frequency |
| Power requirement: | 230v, typically average up to 3amps, max approx 6amps |
| Connections on rear: | Signal via XLR in & link out. / Power via 20A Powercon connectors in & link out. |
| Controls on rear: | Input gain & Leveliza threshold adjustments, mode switch & power switch |
| Display on rear: | Green & Red signal indicators / Blue Leveliza/Limitiza active indicator / Red power indicator. |
